--> Figure 3

Datapages, Inc.Print this page

Figure 3. Wide-Azimuth Designs C and D. The recording patch is 24 lines of 96 channels with individual channels spaced 220 feet apart. The receiver lines are 880 feet apart. Overall, the resulting square patch is 20,900 feet long in the in-line direction and 20,240 feet wide in the cross-line direction.
