Figure. 2.10. Anhydrite filled relict porosity in pisolitic bioclastic grapestone grainstone. The original isopachous cements fringing the pore have been dolomitized along with the rest of the carbonates in this section. Left - plane light; Right - crossed polarizers. Gissler B #29, 1911.4 feet depth, LA = 0.38 mm.
