FIGURE 13. Plain light (left side) and ultraviolet (right side) core photos from Diana 3 well. The cored interval is comprised of sharp-based, upward-fining channels (red arrows mark interpreted channel bases) and individual channel-fill successions that can be further subdivided into channel-axis, channel off-axis, and channel-margin associations. Note: core depth is in feet (modified from Sullivan and Templet, 2002). See Figure 14 for key to bed types.
