Figure 1. Narrow-Azimuth Design A. The recording patch is 10 lines of 96 channels with individual channels spaced 220 feet apart. The receiver lines are 880 feet apart. Overall, the resulting rectangular geometry is 20,900 feet long in the in-line direction and 7920 feet wide in the cross-line direction.
