Figure 6: Using multibody detection, all of the voxels with an amplitude greater than 12,000 are highlighted, and a histogram of the sizes of detected bodies is created. Bodies can then be eliminated based on size. In the middle frames only the 10 largest anomalies are still highlighted. On the right, only the largest anomaly in the trim volume is left.
